Analogue/Digital Voice
| Product | Description | Voice-data Scheme | Voice-band Codec | Supply Voltage (V) | Typ. Current (mA) | Package Type | Additional Features | Key Benefits |
|---|---|---|---|---|---|---|---|---|
| CMX639 | CVSD Voice Codec | CVSD | Yes | 3.0 – 5.5 | 1.9 | 16-SOIC 24-TSSOP | I/O Filters | General purpose error tolerant voice coding scheme. |
| CMX649 | Adaptive Delta Modulation (ADM) Codec | ADM PCM CVSD | Yes | 2.7 – 5.5 | 2.9 | 20-TSSOP 20-SOIC | I/O Filters | General purpose error tolerant voice coding scheme. |
| CMX655D | Ultra-low Power Voice Codec | PCM (linear, A-law, µ-law) | Yes | 1.8 – 3.6 | 300µA | 24-VQFN | 1W Speaker Driver | MEMS microphone support Ultra-low operating power consumption |
No matching results.
| Product | Description | FDMA Systems | TDMA Systems | LD or I/Q Interface | Embedded Functions | Supply Voltage (V) | Typ. Current (mA) | Typ. Power Consumption (mW) | Package type |
|---|---|---|---|---|---|---|---|---|---|
| CMX264 | Voice Scrambler | Analogue PMR/LMR | / | / | Frequency Domain Split-band Scrambler IC | 3.0 – 3.7 | 3 | / | 24-SSOP |
| CMX7158 | Duplex Audio Scrambler | PMR and LMR | / | / | DTMF, Selcall | 3.0 – 3.6 | 6.3 | / | 48-VQFN |
| CMX823 | Programmable Paging Tone Decoder | Tone Paging | / | LD | Selcall Tone Paging | 2.7 – 5.5 | 1 | / | 16-SSOP |
No matching results.
| Product | Description | Voice-data Scheme | Voice-band Codec | Supply Voltage (V) | Typ. Current (mA) | Package Type | Additional Features | Key Benefits |
|---|---|---|---|---|---|---|---|---|
| CMX618/638 | Low-cost 2400bps Vocoder | RALCWI ™ | Yes | 3.0 – 3.6 | 20 | 48-VQFN 48-LQFP | I/O Filters | Low-cost 2400bps Vocoder with robust FEC. CMX638 offer duplex operation. |
| CMX7261 | Digital Voice Multi- transcoder | ADM, CVSD, PCM G.729A, G.711, G.723.1 | Yes | 3.0 – 3.6 | 52 | 64-VQFN | I/O Filters | Performs as a group of audio codecs. |
No matching results.
Baseband Processors
| Product | Description | FDMA Systems | TDMA Systems | LD or I/Q Interface | Embedded Functions | Supply Voltage (V) | Typ. Current (mA) | Typ. Power Consumption (mW) | Package type |
|---|---|---|---|---|---|---|---|---|---|
| CMX138A | Audio Scrambler and signalling Processor | PMR446, FRS, MURS, GMRS, Leisure Radio | / | LD | Audio Processing, CTCSS, DCS, Programmable Tones, ADC, DAC, RAMDAC, GPIO, System Clocks | 3.0 – 3.6 | 9 | / | 3.0 – 3.6 |
| CMX148 | PMR Audio and Data Processor | PMR446, FRS, MURS, GMRS, Leisure Radio | / | LD | Audio Processing, FFSK/MSK, DTMF ADC, DAC, RAMDAC, GPIO, System Clocks | 3.0 – 3.6 | 10 | / | 28-TSSOP |
| CMX7031/CMX7041 | Two-way Radio Processor | Analogue PMR/LMR, Marine VHF, Amateur AX.25 | / | LD | Audio Processing, CTCSS, DCS, DTMF, Selcall, XTCSS, Programmable Tones, ADCs,DACs, RAMDAC, GPIO, System Clocks | 3.0 – 3.6 | 7 | / | 48-VQFN 48-LQFP |
| CMX7131/CMX7141 | Multi-standard Digital PMR (dPMR) Processor | dPMR446 dPMR ™ Mode 1/2/3 ARIB STD-T98 DCR/ARIB STD-T102 NXDN™ AnaloguePMR | / | LD/IQ | AIr Interface Protcols: Physical and Data Link Layers, Audioband Codec AUX ADCs/DACs, RAMDAC, GPIO and System Clocks | 3.0- 3.6 | 4.4 | / | 48-VQFN/LQFP 64-VQFN/LQFP |
| CMX7241/CMX7341 | PMR Common Platform Processor | dPMR™ Mode 1/2/3 Analogue PMR | DMR PDT | LD or I/Q | Automatic Digital and Analogue detection Air Interface Protocols: Physical and Data Link Layers, Complete Analogue Processing AUX ADCs/DACs, RAMDAC, 4FSK, GPIO and System Clocks | 3.0 – 3.6 | 4.4 | / | 48-VQFN 48-LQFP |
| CMX838 | Family Radio Processor | FRS, GMRS, PMR446 | / | LD | Audio Processing, CTCSS | 2.7 – 5.5 | 13 | / | 28-TSSOP |
| CMX881 | Baseband Processor for PMR and Trunked Radio | PMR Trunked Radio | / | LD | Audio Processing, FFSK/MSK, DTMF, CTCSS, DCS, Selcall, Programmable Tones ADC | 2.7 – 5.5 | 5 | / | 28-TSSOP |
| CMX882 | Baseband Processor for PMR and GPS Data Signalling | PMR446, FRS, MURS, GMRS, Leisure Radio | / | LD | Audio Processing, DTMF, CTCSS, DCS, Selcall, Programmable Tones ADC | 2.7 – 3.6 | 5 | / | 28-TSSOP |
| CMX883 | Baseband Processor | PMR446, FRS, MURS, GMRS, Leisure Radio | / | LD | Audio Processing, CTCSS, DCS, XTCSS, ADC | 2.7 – 3.6 | 5 | / | 28-TSSOP |
| PE0003 | PE0003 – Universal Interface Card | ||||||||
| SCT3258TD | DMR/dPMR Processor with embedded Vocoder | dPMR Analog PMR | DMR | I/Q | Full baseband processing Layers 1/2/3 AMBE+2 Vocoder RALCWI Vocoder | Core 1.3 V IO 2.5 – 3.6 V | / | 64mW DMR 38mW dPMR | QFN 64-pin |
| SCT3268TD | DMR/dPMR Processor with Analog Mode | dPMR Multi-mode Digital PMR/LMR with Analog Mode | DMR | LD or I/Q | AMBE+2™ RALCWI ™ | Core 1.2 V Digital IO 2.5 V – 3.3 V | / | 64mW DMR 38mW dPMR | BGA 144 |
| SCT3288 | SCT3288 – Advanced Baseband Processor |
No matching results.
| Product | Description | AIS | Modem | Voice | Auxiliary Functions | Supply Voltage (V) | Typ. Current (mA) | Package Type | Key Benefits |
|---|---|---|---|---|---|---|---|---|---|
| CMX7032/CMX7042 | AIS Baseband Processor | Class B Dual Rx exactTrax™ | GMSK DSC | / | ADCs DACs RAMDAC System Clks | 3.0 – 3.6 | 20 | 48-VQFN 48-LQFP | Function Images support: AIS Class B Dual AIS Rx |
| CMX7341 | Marine Common Platform Processor | MoB | GMSK DSC | / | ADCs DACs RAMDAC System Clks | 3.0 – 3.6 | 32 Rx 20 Tx | 48-LQFP | Integrated low power MoB Solution |
| CMX885 | Maritime VHF Processor | / | DSC | Yes | ADCs DACs RAMDAC System Clks | 3.0 – 3.6 | 8 | 48-VQFN 48-LQFP | Low cost Maritime VHF voice and DSC processing Includes ADCs, DACs, RAMDAC and system clocks |
| CMX910 | AIS Class A Baseband Processor | Class B | GMSK DSC | / | ADCs DACs | 3.0 – 3.6 | 35 | 64-VQFN | Complete AIS Class A Processor |
| DE70322T | AIS Class B Demonstration Kit | Class B Dual Rx | GMSK | No | USB RS232 GPIO Alarm GNSS | 5V Nominal 4.5 – 6.0 VDC | Module 122 x 57 mm | Complete 2-Channel Rx design Fast path to Class B design Upgrade path to other AIS product | |
| SCT7033 | Maritime AIS Class B CSTDMA Demonstration Kit | Class B | GMSK | No | USB RS232 GPIO | 5V Nominal 4.5 – 6.0 VDC | Module 122 x 57 mm | Complete 2W Class B CSTDMA design reference Fitted with SCT7033 for full protocol stack USB and RS485 Interface Firmware upgrades Upgrade path to other AIS products |
No matching results.
Data Modems
| Product | Description | Modulation Schemes | Data Range (kbps) | Supply Voltage (V) | Typ. Current (mA) | Package Type | Auxiliary Features | Key Benefits |
|---|---|---|---|---|---|---|---|---|
| CMX7143 | Multi-mode Wireless Data Modem | FFSK/MSK GMSK/GFSK 4FSK | FFSK | 3.0 – 3.6 | Rx 11.7 Tx 15.7 | 48-VQFN 48-LQFP | ADCs, DACs System Clocks GPIO RAMDAC | Multi-mode packet data modem for FR LD systems |
| CMX7146 | BPSK Wireless Data Modulator | BPSK/PRK/2PSK | 0.6 – 9.6 | 3.0 – 3.6 | 7 (1200bps) 15 (9600bps) | 48-VQFN | ADCs, DACs System Clocks GPIO RAMDAC | Small low power BPSK Modulator |
| CMX7163 | QAM (I/Q) Wireless Data Modem | 4/16/32/64 QAM | QAM | 3.0 – 3.6 | Rx 18.7 Tx 12.7 | 64-VQFN 64-LQFP | ADCs, DACs System Clocks GPIO RAMDAC | High speed QAM packet data modem for I/Q based systems |
| CMX7164 | Multi-mode (I/Q) Wireless Data Modem | GMSK/GFSK 2/4/8/16 FSK 4/16/32/64 QAM V.23 Modem | GMSK | 3.0 – 3.6 | Rx 17.9 Tx 12.7 | 64-VQFN 64-LQFP | ADCs, DACs System Clocks GPIO RAMDAC | Multi-mode packet data modem for I/Q based systems |
| CMX7364 | CMX7364 – Multi-mode High Performance Wireless Data Modem | |||||||
| CMX7364 | CMX7364 RTCM SC135 Compliant RTK Wireless Modem | |||||||
| DE9941A | DE9941A – SDR Demonstrator for Industrial IoT Modem Applications |
No matching results.
| Product | Description | Modulation Schemes | Data Range (kbps) | Supply Voltage (V) | Typ. Current (mA) | Package Type | Key Benefits |
|---|---|---|---|---|---|---|---|
| CMX469A | 1200/2400/4800 Baud FFSK/MSK Modem | 1200 2400 4800 | 3.0 – 5.5 | 3.0 – 5.5 | 4.5 | 20-SOIC 24-TSSOP | General purpose audio-band FFSK modem data-pump |
| CMX589A | Full-duplex GMSK Modem | GMSK/GFSK | 3.0 – 5.5 | 4 | 16-SOIC 16-TSSOP | General purpose high speed GMSK modem data-pump | |
| CMX909B | GMSK Packet Data Modem | GMSK | 38.4 | 2.7 – 5.5 | 24-TSSOP 24-SSOP | General purpose GMSK packet data modem | |
| CMX969 | RD-LAP, MCD4800 Motient/ARDIS Packet Data Modem | 4FSK FSK | RD-LAP =19.2 MCD =4.8 | 2.7 – 5.5 | 4 | 24-TSSOP 24-SSOP | RD-LAP, MDC2800, Motient/ARDIS conformance |
| FX919B/MX919B | 4FSK Packet Data Modem | 4FSK | 19.2 | 3.0 – 5.5 | 4 | 24-SOIC | General purpose 4FSK packet data modem |
No matching results.
| Product | Description | V.22 | V.23 | V.21 | Bell 202 | Bell 103 | DTMF | CLI | Supply Voltage (V) | Typ. Current (mA) | Package Type | V.32 | Key Benefits |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CMX867A | V.22 Modem | Yes | Yes | Yes | Yes | Yes | Yes | Yes | 2.7 – 5.5 | 3 | 24-pin SOIC TSSOP | Ring Detect, USART Hybrid support, Line equalisation | |
| CMX868A | V.22 bis Modem | Yes bis | Yes | Yes | Yes | Yes | Yes | Yes | 2.7 – 5.5 | 3 | 24-pin SOIC TSSOP | / | Ring Detect, USART Hybrid support, Line equalisation |
| CMX869B | V.32 bis Modem | Yes bis | Yes | Yes | Yes | Yes | Yes | Yes | 3.0 – 3.6 | 8.6 | 24-pin SOIC TSSOP | Yes | Ring detect, USART, Hybrid support, Line equalisation |
No matching results.
| Product | Description | Data | Signalling | Supply Voltage (V) | Typ. Current (mA) | Package Type | V.23 | V.21 | Bell 202 | Bell 103 | DTMF | Key Benefits |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CMX602B | Calling Line Identifier Plus Call Waiting | V.23 Demodulation | CLI Decoder CIDCW Decoder | 2.7 – 5.5 | 0.5 | 16-pin SOIC TSSOP | Featurephone applications | |||||
| CMX673 | Call Progress Tone Detector | Single Call Progress Dual Tone Detectors | 2.7 – 5.5 | 0.5 | 16-pin SOIC 20-pin TSSOP | Universal call progress detector | ||||||
| CMX683 | Call Progress Tone Detector Plus Voice Detector | Single Call Progress Dual Tone Detectors | 2.7 – 5.5 | 0.6 | 16-pin SOIC TSSOP | Call progress detector with voice detection | ||||||
| CMX865A | DTMF/FSK Combo | 3.0 – 5.5 | 1 | 16-pin SOIC | Yes | Yes | Yes | Yes | Yes | PABX applications | ||
| FX604/MX604 | V.23 Compatible Modem | 3.0 – 5.5 | 1 | 16-pin SOIC | Yes | PABX applications | ||||||
| FX614/MX614 | Bell 202 Compatible Modem | 3.0 – 5.5 | 1 | 16-pin SOIC | Yes | Ideally suited to WLL, FWT, CWT, Hart applications |
No matching results.
RF Building Blocks
| Product | Description | Type | Frequency Range | Bandwidth | Baseband / Modulation | Supply Voltage (V) | Typ. Current (mA) | Typ. Power Consumption (mW) | Package Type | RF/IF Range (MHz) | I/Q BW (MHz) | Input IP3 (dBm) | Noise Figure (dB) | Gain (dB(V/V)) | Key Benefits |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CMX918 | Low Power Software Defined Radio (SDR) Tuner | IC | 0.15 MHz – 108 MHz | 10 kHz – 200 kHz | I/Q | 2.9 – 3.6 | 28.5 mA @ FM | 95 mW @ 3.3 V | Q5 QFN | ||||||
| CMX994EF | RF Direct Conversion Receiver IC | 3.0 – 3.6 | 74 | 40 – VQFN | 100 – 1000 | >1 | 6 | 6 | 62 | Very high IIP2 for true-zero IF DCRx use, low power, complete LNA to zero-IF receiver path, IF filter, gain controls, flexible LO divider for Tx and Rx synth with VCO amp |
No matching results.
| Product | Description | RF/IF Range (MHz) | I/Q BW (MHz) | Output IP3 (dBm) | Noise Floor (dBm/Hz) | Output Power (dBm) | Supply Voltage (V) | Typ. Current (mA) | Package Type | Key Benefits |
|---|---|---|---|---|---|---|---|---|---|---|
| CMX993/CMX993W | RF Quadrature Modulator | 30 – 1000 | 10 | 25 | -155 | 3 (PEP) | 3.0 -3.6 | 95 | 48-VQFN | Amplifiers for analogue scaling and filtering, output gain control, flexible LO divider |
| CMX998 | Cartesian Feedback Loop | 30 – 1000 | 0.2 | -155 | 3 (PEP) | 3.0 – 3.6 | 135 | 64-VQFN | I/Q modulator-based subsystem greatly linearises external RF PA |
No matching results.
| Product | Description | Supply Voltage (V) | Package Type | Tx RF/IF Range (MHz) | Tx I/Q BW (MHz) | Tx IP3 OP/IP (dBm) | Tx Noise / Noise Figure (dBm/Hz)/(dB)) | Tx Power / Gain (dBm) / (dbV/V)) | Tx Typ. Current (mA) | Rx RF/IF Range (MHz) | Rx I/Q BW (MHz) | Rx IP3 OP/IP (dBm) | Rx Noise / Noise Figure (dBm/Hz)/(dB)) | Rx Power / Gain (dBm) / (dbV/V)) | Rx Typ. Current (mA) | FDMA Systems | TDMA Systems | LD or I/Q Interface | Embedded Functions | Typ. Current (mA) | Typ. Power Consumption (mW) | Package type | Key Benefits |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CMX973 | Low Power RF Quadrature | 3.0 – 3.6 | 32-VQFN | 20 -1000 | 25 | 14 | -150 | 0 (PEP) | 61 | 20 – 300 | 10 | -15 | 10db | 56dB | 15 | Very low power, small size, excellent performance, flexible LO divider, synth with VCO amp | |||||||
| SCT2400 | 2.4GHz Digital Voice and Data Transceiver | Core 3.3 V | Proprietary | / | Complete 2.5GHz Transceiver | Vocoder Wireless data modem Protocol engine System Controller | 10 (standby/scanning) 52 (receive voice) 64 (transmit voice) | / | BGA 144 |
No matching results.
| Product | Description | RF/IF Range MHz | Normalised PN (dBc/Hz) | Max Fcomp (MHz) | PN at 25kHz (dBc/Hz) | Supply Voltage (V) | Typ. Current (mA) | Package Type | Key Benefits |
|---|---|---|---|---|---|---|---|---|---|
| CMX940 | High Performance Synthesizer (HPS) | 49 MHz – 2040 MHz | -225 | 120 | -123 (at 435 MHz) | 3.0 – 3.6 | 23 – 64 | 40-LGA | Low Power High Performance RF Synth with Integrated VCO |
No matching results.
| Product | Description | FDMA Systems | TDMA Systems | LD or I/Q Interface | Embedded Functions | Supply Voltage (V) | Typ. Current (mA) | Typ. Power Consumption (mW) | Package type |
|---|---|---|---|---|---|---|---|---|---|
| CMX983 | Analogue Front End (AFE) for Digital Radio | Universal | Universal | I/Q | Channel Filters, Audioband Codec, AUX, ADCs, DACs, RAMDAC, GPIO and Speaker Amp, 2 Frac-N Synths | 3.0 – 3.6 | / | / | 64-VQFN |
No matching results.
Subsystems
| Product | Description | Type | Frequency Range | Bandwidth | Baseband / Modulation | Supply Voltage (V) | Typ. Current (mA) | Typ. Power Consumption (mW) | Package Type |
|---|---|---|---|---|---|---|---|---|---|
| DE9180 | DE9180 Demonstration and Prototyping Kit for the DRM1000 Broadcast Receiver Module | ||||||||
| DRM1000 | Broadcast Receiver Module | Module | 0.15 MHz – 108 MHz | 10 kHz – 200 kHz | AM/FM/DRM | 2.7 – 3.6 | 67.9 mA @ DRM | 225 mW | 42 Pin Module |
| PE0004 | PE0004 Evaluation Kit Interface Card |
No matching results.
| Product | Description | AIS | Modem | Voice | Auxiliary Functions | Supply Voltage (V) | Typ. Current (mA) | Package Type | Key Benefits |
|---|---|---|---|---|---|---|---|---|---|
| VDES1000 | Complete VDES Solution | Class-A | ASM Transceiver VDE Transceiver | No | 6 x Isolated RS442 Ethernet 100 base-T | 24V | / | Module 165mm x 100mm x 30mm | Complete SDR maritime VDES (AIS,ASM and VDE) solution |
No matching results.
SμRF Amplifiers
| Product | Description | Frequency (MHz) | Gain (dB) | Psat (dBm) | Efficiency (%) | Voltage (V) | Bias Current (mA) | RF Match | Package (mm) | P1dB (dBm) |
|---|---|---|---|---|---|---|---|---|---|---|
| CMX90A003 | CMX90A003 1W 860 – 960 MHz Power Amplifier | 860 – 960 | 30 | 29.5 | 49% | 1.9 – 3.0 | 70 | Int / Int | 4×4 QFN | |
| CMX90A004 | CMX90A004 2W 860 –960 MHz Power Amplifier | 860 – 960 | 30 | 32.5 | 49% | 2.7 – 4.5 | 78 | Int / Int | 4×4 QFN | |
| CMX90A006 | CMX90A006 2W 860-930 MHz Linear PA | 860 – 930 | 33 | 33.5 | 52% | 2.5 – 5.25 | 206 | Int / Ext | 4×4 QFN | 33 |
| CMX90A007 | CMX90A007 2W 136 – 1000 MHz 2-stage Driver Amplifier | 136 – 1000 | 27 | 33.5 | 53% | 6.0 – 9.5 | 49.5 | Ext / Ext | 4×4 QFN | |
| CMX90A009 | CMX90A009 10W 136 – 1000 MHz Power Amplifier | 136 – 1000 | 17.5 | 41.5 | 60% | 6.0 – 9.5 | 136 | Ext / Ext | 4×5 DFN |
No matching results.
| Product | Description | Frequency (GHz) | Gain (dB) | IRL/ORL (dB) | P1dB (dBm) | OIP3 (dBm) | Voltage (V) | Bias Current (mA) | Package (mm) | NF (dB) |
|---|---|---|---|---|---|---|---|---|---|---|
| CMX90A702 | CMX90A702 28 GHz 5G Medium Power Amplifier | 26.5 – 29.5 | 21 | 10 / 7 | 25 | 32.5 | 4 | 182 | 4×4 QFN | |
| MMA-020624 | MMA-020624 2000-6000 MHz Fully Matched High Dynamic Range Amplifier | 2 – 6 | 17 | 12 / 12 | 25 | 40 | 8 | 250 | Die | 3.5 |
| MMA-020624-M4 | MMA-020624-M4 2000-6000 MHz Fully Matched High Dynamic Range Amplifier | 2 – 6 | 17 | 12 / 12 | 25 | 40 | 8 | 250 | 4×4 QFN | 3.5 |
| MMA-053223-M4 | MMA-053223-M4 500-3200 MHz Fully Matched High Dynamic Range Amplifier | 0.5 – 3.2 | 12 | 10 / 10 | 24 | 42 | 6 | 120 | 4×4 QFN | 3 |
| MMA-054025-M4 | MMA-054025-M4 500-4000 MHz Fully Matched High Dynamic Range Amplifier | 0.5 – 4 | 11 | 10 / 10 | 25 | 44 | 7.5 | 300 | 4×4 QFN | 3.5 |
No matching results.
| Product | Description | Frequency (GHz) | Gain (dB) | P1dB (dBm) | OIP3 (dBm) | IRL/ORL (dB) | Voltage (V) | Package (mm) |
|---|---|---|---|---|---|---|---|---|
| MMA-445933H-02 | MMA-445933H-02 4.4 – 5.9 GHz 2W High Efficiency Linear Power Amplifier | 4.4 – 5.9 | 33 | 33 | 45 | 10 / 7 | 7.5 | 11X7 02 |
| MMA-445933H-M5 | MMA-445933H-M5 4.4 – 5.9 GHz 2W High Efficiency Linear Power Amplifier | 4.4 – 5.9 | 31 | 33 | 45 | 13 / 7 | 7.5 | 5X5 QFN |
| MMA-495930-Q4 | MMA-495930-Q4 4.9-5.9GHz Fully Matched Medium Power Amplifier | 4,9 -5.9 | 20 | 30 | 45 | 8 / 8 | 7.5 | 4 X 4 QFN |
| MMA-495933-M5 | MMA-495933-M5 4.9 – 5.9 GHz Linear Power Amplifier | 4.9 – 5.9 | 11 | 33 | 46 | 12 / 5 | 7.5 | 5X5 QFN |
No matching results.
| Product | Description | Frequency (GHz) | Gain (dB) | P1dB (dBm) | Psat (dBm) | OIP3 (dBm) | IRL/ORL (dB) | Voltage (V) | Package (mm) |
|---|---|---|---|---|---|---|---|---|---|
| MMA-121633-M5 | MMA-121633-M5 12.5-15.5GHz, 2W Power Amplifier | 12.5 – 15.5 | 23.5 | 32 | 34 | 42 | 10 / 10 | 4 – 6 | 5X5 QFN |
| MMA-172135-M5 | MMA-172135-M5 17-21GHz, 3W Power Amplifier | 17 – 21 | 27 | 35 | 42.5 | 12 / 12 | 6 | 5X5 QFN | |
| MMA-172135D | MMA-172135D 17-21GHz, 3W Power Amplifier | 17 – 21 | 27 | 35 | 12 / 10 | 6 | Die | ||
| MMA-212734D-M5 | MMA-212734D-M5 21-27GHz, 3W Power Amplifier | 21 – 27 | 25 | 33 | 34 | 15 / 15 | 6 | 5X5 QFN | |
| MMA-243034D-M5 | MMA-243034D-M5 24 – 30 GHz, 2.5W MMIC Power Amplifier | 24 – 30 | 23 | 34 | 34.5 | 8 / 10 | 6 | 5X5 QFN | |
| MMA-273034D-M5 | MMA-273034D-M5 27 – 30 GHz, 2.5W MMIC Power Amplifier | 27 – 30 | 26 | 33 | 34.5 | 10 / 10 | 6 | 5X5 QFN | |
| MMA-273036-M5 | MMA-273036-M5 27.5-30GHz 4W MMIC Power Amplifier | 27.5 – 30 | 22 | 36 | 36.5 | 10 / 10 | 6 | 5X5 QFN | |
| MMA-273334D-M5 | MMA-273334D-M5 27 – 33 GHz, 2.5W MMIC Power Amplifier | 27 – 33 | 22 | 33 | 34 | 10 / 10 | 6 | 5X5 QFN | |
| MMA-273336-M5 | MMA-273336-M5 27-33GHz 4W MMIC Power Amplifier | 27 – 33 | 22 | 36 | 36.5 | 38 | 10 | 6 | 5X5 QFN |
| MMA-273336D-M5 | MMA-273336D-M5 27-33GHz 4W MMIC Power Amplifier | 27 – 33 | 22 | 35.5 | 36.5 | 38 | 10 / 10 | 6 | 5X5 QFN |
| MMA-374030-M5 | MMA-374030-M5 37-41GHz, 1W MMIC Power Amplifier | 37 – 41 | 22 | 29 | 31 | 38 | 10 / 10 | 4 – 6 | 5X5 QFN |
No matching results.
| Product | Description | Frequency (GHz) | Gain (dB) | P1dB (dBm) | P3dB (dBm) | Gain Flatness (dB) | OIP3 (dBm) | IRL/ORL (dB) | Voltage (V) | Package (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| MMA-005022-M4 | MMA-005022-M4 30KHz-50GHz Traveling Wave Amplifier | 30 kHz – 50 | 13.5 | 22 | 25 | +/- 2.0 | 30 | 10 / 10 | 7 | 4X4 QFN |
| MMA-005022B | MMA-005022B 30KHz-50GHz Traveling Wave Amplifier | 30 kHz – 50 | 13.5 | 22 | 25 | +/- 1.0 | 30 | 15 / 15 | 7 | Die |
| MMA-012030 | MMA-012030 0.1-20GHz 1W Traveling Wave Amplifier | 0.1 – 20 | 12.5 | 27 | 29 | +/- 0.5 | 37 | 10 / 10 | 12 | Die |
| MMA-012030-M4 | MMA-012030-M4 | 0.1 – 20 | 12.5 | 27 | 29 | +/- 0.5 | 37 | 10 / 10 | 12 | 4X4 QFN |
| MMA-012727 | MMA-012727 0.1-26.5GHz 0.5W Traveling Wave Amplifier | 0.1 – 26.5 | 12.5 | 26 | 27 | +/- 0.5 | 35 | 11 / 11 | 8 – 12 | Die |
| MMA-012727-M4 | MMA-012727-M4 0.1-26.5GHz 0.5W Traveling Wave Amplifier | 0.1 – 26.5 | 12.5 | 26 | 27 | +/- 0.5 | 35 | 11 / 11 | 8 – 12 | 4X4 QFN |
No matching results.
| Product | Description | Frequency (GHz) | Gain (dB) | P1dB (dBm) | IRL/ORL (dB) | OIP3 (dBm) | NF (dB) | Voltage (V) | Bias Current (mA) | Package (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| CMX90B701 | CMX90B701 Low Current/Noise Gain Block 17 – 23 GHz | 17 – 23 | 17.2 | 7.5 | 6 / 10 | 17.5 | 4.0 | 3 – 5 | 10 | 3×3 QFN |
| CMX90B702 | CMX90B702 Low Current/Noise Gain Block 23 – 29.5 GHz | 23 – 29.5 | 17.5 | 5.0 | 6 / 8 | 15.0 | 4.0 | 3 – 5 | 10 | 3×3 QFN |
| CMX90G301 | CMX90G301 [1.4 – 7.1 GHz] Positive Gain-Slope Amplifier +1 dB | 1.4 – 7.1 | 14.8 – 16 | 11.5 | 21.0 | 1.9 | 2.7 – 5 | 22 | 3×3 QFN | |
| CMX90G302 | CMX90G302 [1.4 – 7.1 GHz] Positive Gain-Slope Amplifier +2 dB | 1.4 – 7.1 | 14.8 – 16.9 | 11.5 | 21.0 | 1.9 | 2.7 – 5 | 22 | 3×3 QFN | |
| CMX90G701 | CMX90G701 Positive Gain Slope Amplifier +1dB | 6 – 18 | 9.4 – 10.4 | 10.0 | 19.0 | 2.6 | 2 – 5 | 22 | 3×3 QFN | |
| CMX90G702 | CMX90G702 Positive Gain Slope Amplifier +2dB | 6 – 18 | 9.1 – 11.1 | 9.5 | 18.5 | 3.0 | 2 – 5 | 22 | 3×3 QFN | |
| MMA-011015 | MMA-011015 1 – 10 GHz GaAs MMIC Medium Power Amplifier | 1 – 10 | 15.0 | 16.0 | 12 / 15 | 4.5 | 6 | 75 | Die | |
| MMA-011015-C3 | MMA-011015-C3 1 – 10 GHz Fully Matched Driver Amplifier | 1 – 10 | 15.0 | 16.0 | 12 / 15 | 4.5 | 6 | 75 | 3×3 QFN | |
| MMA-062020 | MMA-062020 6-22GHz, 0.1W Gain Block | 6 – 20 | 14.0 | 18.3 | 8 / 10 | 28.0 | 3 – 6 | 120 | Die | |
| MMA-062020-C3 | MMA-062020-C3 6-22GHz, 0.1W Gain Block | 6 – 22 | 14.0 | 18.5 | 8 / 10 | 28.0 | 3 – 6 | 130 | 3×3 QFN | |
| MMA-174321 | MMA-174321 17-43GHz, 0.1W Gain Block | 17 – 43 | 21.0 | 18.0 | 8 / 8 | 26.0 | 3 – 5 | 150 – 250 | Die | |
| MMA-174321-M4 | MMA-174321-M4 17 – 43GHz, 0.1W Gain Block | 17 – 43 | 18.0 | 21.0 | 8 / 8 | 26.0 | 3 – 5 | 150 – 250 | 4×4 QFN |
No matching results.
| Product | Description | Frequency (GHz) | Band | Gain (dB) | Psat (dBm) | IRL/ORL (dB) | Package (mm) | Gain Flatness (dB) | Pout @ -3 dB (dBm) | Pout @ 2.5% EVM | Vdd (V) | Bias Current (mA) | Package | DC Power to maintain IM3 (W) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CMX90A705 | CMX90A705 5.5W Ka-Band GaN Power Amplifier | 27.5 – 31 | Ka-band | 16.5 | 37.4 | 10 / 9 | 4 x 4 QFN | |||||||
| MGA-242740-02 | MGA-242740-02 2.4 – 2.7 GHz 10W High Efficiency Linear Power Amplifier | 2.4 – 2.7 | 15 | 8 / 8 | 1 | 40 | 33 | 28 | 50 – 400 | 2 | ||||
| MGA-333840-02 | MGA-333840-02 3.3 – 3.8 GHz 10W High Efficiency Linear Power Amplifier | 3.3 – 3.8 | 12 | 8 / 8 | 1 | 40 | 33 | 28 | 100 – 400 | 2 | ||||
| MGA-444940-02 | MGA-444940-02 4.4 – 4.9 GHz 10W High Efficiency High Power Amplifier | 4.4 – 4.9 | 12 | 8 / 10 | 1 | 40 | 33 | 28 | 100 – 400 | 2 | ||||
| MGA-445343-99 | MGA-445343-99 4.4 – 5.3 GHz 20W High Efficiency Linear Power Amplifier | 4.4 – 5.3 | 14 | 7 / 4 | 1 | 43 | 35 | 28 | 150 – 300 | 99 | ||||
| MGA-445940-02 | MGA-445940-02 4.4 – 5.9 GHz 10W High Efficiency Linear Power Amplifier | 4.4 – 5.9 | 14 | 6 / 3 | 1 | 40 | 34 | 28 | 100 – 1200 | 2 | ||||
| MGA-495940-02 | MGA-495940-02 4.4 – 5.9 GHz 10W High Efficiency Linear Power Amplifier | 4.9 – 5.9 | 14 | 8 / 8 | 1 | 40 | 33 | 28 | 100 – 400 | 2 | ||||
| MGA-515844-99 | MGA-515844-99 5.1 – 5.8 GHz 25W High Efficiency Linear Power Amplifier | 5.1 – 5.8 | 16 | 10 / 12 | 1 | 44 | 35 | 28 | 99 | |||||
| MGA-718540-HP3 | MGA-718540-HP3 7.1 – 8.5 GHz 10W High Efficiency GaN Power Amplifier | 7.1 – 8.5 | 14 | 10 / 7 | 1 | 42 | 28 | 1300 | HP3 | |||||
| MGA-718544-HP3 | MGA-718544-HP3 7.1 – 8.5 GHz 25W GaN Power Amplifier | 7.1 – 8.5 | 13.5 | 4.5 / 6 | 1 | 44 | 28 | 2400 | HP3 | |||||
| MMG-121543-S5 | MMG-121543-S5 20 Watt 1.2-1.5 GHz GaN Power Amplifier | 1.2 – 1.5 | L-band | 28.5 | 43 | 11 / 13 | 5 x 5 QFN | 20 | ||||||
| MMG-202543-S5 | MMG-202543-S5 20 Watt 2.0 – 2.5 GHz GaN Power Amplifier | 2.0 – 2.5 | S-band | 27 | 44 | 7 / 12 | 5 x 5 QFN | 25 | ||||||
| MMG-446040-S5 | MMG-446040-S5 10 Watt 4.4 – 6.0 GHz GaN Power Amplifier | 4.4 – 6.0 | C-band | 30 | 40 | 7 / 15 | 5 x 5 QFN | 10 |
No matching results.
SμRF Discretes
| Product | Description | Package Available Sealed/ Hermetic | RF Power @12 GHz (dBm) | Small Signal Gain @12 GHz (dB) | PAE @12GHz (%) | Chip Size (µm) | Gate Width (µm) | Gate Pads (each) | Drain Pads (each) | Replaces | NF @12GHz (dB) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MwT-11F | MwT-11F High Power, High Linearity GaAs FET | 71 | 32 | 9 | 40 | 775 x 343 | 2400 | 2 | 2 | MwT-11 | |
| MwT-1F | MwT-1F 12 GHz High Gain GaAs FET | 70 / 71 / 73 | 26 | 10 | 775 x 241 | 630 | 1 | 1 | MwT-1 | 2 | |
| MwT-3F | MwT-3F 26 GHz High Power GaAs FET | 70 / 71 / 73 | 22 | 14 | 35 | 406 x 241 | 300 | 1 | 1 | MwT-3 | |
| MwT-5F | MwT-5F 26 GHz High Gain, Dual Gate GaAs FET | 71 | 21 | 19 | 406 x 241 | 300 Dual | 1 | 3 | MwT-5 | 3.5 | |
| MwT-7F | MwT-7F 26 GHz Medium Power GaAs FET | 70 / 71 / 73 | 21 | 15 | 356 x 241 | 250 | 2 | 2 | MwT-7, S7, LP7 | 2 | |
| MwT-9F | MwT-9F 18 GHz Medium Power GaAs FET | 71 | 26.5 | 11 | 35 | 419 x 241 | 750 | 1 | 1 | MwT-9, A9 |
No matching results.
| Product | Description | Package Available Sealed/ Hermetic | RF Power @12 GHz (dBm) | Small Signal Gain @12 GHz (dB) | PAE @12GHz (%) | Chip Size (µm) | Gate Width (µm) | Gate Pads (each) | Drain Pads (each) | Replaces |
|---|---|---|---|---|---|---|---|---|---|---|
| MwT-PH11 | MwT-PH11 F/MwT-PH11FV 12 GHz High Power AlGaAs/InGaAs pHEMT | 71 | 32 | 12 | 45 | 775 x 365 | 2400 | 2 | 2 | MwT-PH11 |
| MwT-PH15F | MwT-PH15F 28 GHz Medium Power AlGaAs/InGaAs pHEMT | 71 | 28 | 16 | 60 | 850 x 260 | 630 | 4 | 2 | MwT-PH15 |
| MwT-PH27F | MwT-PH27F 26 GHz Medium Power AlGaAs/InGaAs pHEMT | 70 / 71 / 73 | 25 | 16 | 40 | 410 x 340 | 400 | 1 | 1 | QorvoTGF2040 |
| MwT-PH28F | MwT-PH28F 26 GHz Medium Power AlGaAs/InGaAs pHEMT | 70 / 71 / 73 | 27 | 15 | 45 | 410 x 340 | 600 | 1 | 1 | QorvoTGF2060 |
| MwT-PH29F | MwT-PH29F 18 GHz Medium Power AlGaAs/InGaAs pHEMT | 70 / 71 / 73 | 28.5 | 13 | 45 | 410 x 480 | 800 | 1 | 1 | RFMD FDP750 |
| MwT-PH30F | MwT-PH30F 18 GHz Medium Power AlGaAs/InGaAs pHEMT | 70 / 71 / 73 | 28 | 14 | 45 | 410 x 540 | 800 | 2 | 2 | QorvoTGF2080 |
| MwT-PH31F | MwT-PH31F 18 GHz Medium Power AlGaAs/InGaAs pHEMT | 71 | 30 | 13 | 45 | 540 x 410 | 1200 | 2 | 2 | QorvoTGF2120 |
| MwT-PH32F | MwT-PH32F 12 GHz High Power AlGaAs/InGaAs pHEMT | 71 | 31 | 13 | 45 | 540 x 410 | 1600 | 2 | 2 | QorvoTGF2160 |
| MwT-PH33F | MwT-PH33F 26 GHz Medium Power AlGaAs/InGaAs pHEMT | 70 / 71 / 73 | 24 | 16 | 50 | 315 x 440 | 300 | 1 | 1 | N/A |
| MwT-PH3F | MwT-PH3F 28 GHz Medium Power AlGaAs/InGaAs pHEMT | 70 / 71 / 73 | 24 | 16 | 60 | 410 x 340 | 300 | 1 | 1 | N/A |
| MwT-PH4F | MwT-PH4F 28 GHz Medium Power AlGaAs/InGaAs pHEMT | 70 / 71 / 73 | 22 | 16 | 60 | 365 x 260 | 180 | 1 | 1 | MwT-PH4 |
| MwT-PH7F | MwT-PH7F 28 GHz Medium Power AlGaAs/InGaAs pHEMT | 70 / 71 / 73 | 24 | 16 | 60 | 365 x 260 | 180 | 1 | 1 | MwT-PH7 |
| MwT-PH8F | MwT-PH8F 18 GHz Medium Power AlGaAs/InGaAs pHEMT | 71 | 30 | 13 | 40 | 315 x 690 | 1200 | 2 | 2 | MwT-PH8 |
| MwT-PH9F | MwT-PH9F 26 GHz Medium Power AlGaAs/InGaAs pHEMT | 70 / 71 / 73 | 27 | 14 | 50 | 480 x 315 | 750 | 1 | 1 | MwT-PH9 |
No matching results.
Quick Product Selector
Find the part you need for your application using our product selector.
View Full Product Selector Ready to Build Smarter Wireless Systems?
Speak to our team about your application, discuss your requirements, or explore how CML Micro can support your next design.
