MMA-374030-M5
37-41GHz, 1W MMIC Power Amplifier
MMA-374030-M5
37-41GHz, 1W MMIC Power Amplifier
The MMIC is an OIP3=39dBm high linearity power amplifier in a surface mount package designed for use in transmitters that operate at frequencies between 37GHz and 41GHz. In the operational frequency band, it provides 30.5dBm of output power (P-1dB) and 22dB of small-signal gain. This PA is also designed for high linearity applications, and the PA shows better than -41dBc of IM3 level at 18dBm/tone output power level.
Features of the MMA-374030-M5 37-41GHz, 1W MMIC Power Amplifier include:
- Frequency Range: 37 – 41 GHz
- P1dB: +30.5 dBm
- IM3 Level: -41 dBc @Po=18dBm/tone
- Gain: 22 dB
- Vdd = 4 to 6 V
- Idsq = 1000 to 2000 mA
- Input and Output Fully Matched to 50 Ω
- Integrated power detector
- Surface Mount, RoHs Compliant QFN 5x5mm package
Applications the MMA-374030-M5 37-41GHz, 1W MMIC Power Amplifier can be used for:
- P2P Radio
- V-sat
