MMA-445933H-M5
4.4 – 5.9 GHz 2W High Efficiency Linear Power Amplifier
MMA-445933H-M5
4.4 – 5.9 GHz 2W High Efficiency Linear Power Amplifier
The MMA-445933H is a power amplifier with the State-of-the-Art linear power between 4.4. GHz and 5.9 GHz frequency band. Based on advanced robust HFET device technology, the linearity of this power amplifier is 25 dBm linear power at 2.5% EVM and achieves an ACPR better than -36 dBc. The modulation test pattern is 802.16x 64QAM. This linear power amplifier also has high gain. Ideal applications include the driver and the output power stage of WiMax and WLAN infrastructures and access points. It also can be used for PTP (Point-To-Point) radio applications for this band.
Features of the MMA-445933H-M5 4.4 - 5.9 GHz 2W High Efficiency Linear Power Amplifier include:
- 31 dB Gain
- 33 dBm P-1dB
- OIP3 45 dBm
- 25.0 dBm Linear Pout @ 2.5% EVM (802.11 64QAM)
- Fully Matched Input and Output for Easy Cascade
- Internal Bias Tee
- Surface Mount, RoHS Compliant QFN 5x5mm Package
Applications the MMA-445933H-M5 4.4 - 5.9 GHz 2W High Efficiency Linear Power Amplifier can be used for:
- Driver and the ouput power stage of WiMax and WLAN infrastrucures and access points
