MGA-444940-02
4.4 – 4.9 GHz 10W High Efficiency High Power Amplifier
MGA-444940-02
4.4 – 4.9 GHz 10W High Efficiency High Power Amplifier
The MGA-444940-02 is a power amplifier with the State-of-the-Art linear power-added-efficiency between 4.4 GHz and 4.9 GHz frequency band. Based on advanced robust GaN device technology, the power-added-efficiency of this power amplifier is over 20% at 2W linear burst power with 2.5% EVM and ACPR better than -38 dBc. The modulation test pattern is 802.16x 64QAM. The high efficiency linear power amplifier also has excellent reliability. Ideal applications include the driver and the output power stage of the telemetry, avionics, private microwave network systems, and military wireless communications.
Features of the MGA-444940-02 4.4 - 4.9 GHz 10W High Efficiency High Power Amplifier include:
- GaN Based High Power Amplifier
- 20% Efficiency at 33 dBm Linear Output Power
- 40 dBm P-3dB
- 33 dBm Linear Pout @ 2.5% EVM (802.11 64QAM)
- 12 dB Gain
- Fully Matched Input and Output for Easy Cascase
- +28V Bias Voltage
- RoHS Compliant Surface Mount Package
- MTTF > 100 years @ 85C Ambient Temperature
Applications the MGA-444940-02 4.4 - 4.9 GHz 10W High Efficiency High Power Amplifier can be used for:
- Telemetry
- Avionics
- Private Microwave Network Systems
- Military Wireless Communications
